How to read STAAD Analysis (*.ANL) file using Excel VBA

Extract data from STAAD (*.ANL) file using VBA

Posted
Preview Image
By Vivek Patel
15 min read
How to read STAAD Analysis (*.ANL) file using Excel VBA

Overview

  • In this tutorial, I’ll show you how to extract data from a STAAD Analysis file using Excel VBA.
  • Why?
    • It’s the only way to extract design data from STAAD.
    • You can also extract model info or analysis results if you don’t want to use OPENSTAAD.
  • I am assuming that:
    • You have basic knowledge of VBA and know how to add modules and create new subs.
    • You know how to generate a STAAD Analysis (*.ANL) file and are familiar with its layout.

Setup

  • You’ll need an ANL file that contains design data.
  • For this setup, I am putting the ANL file in the same folder as the Excel file, with the name “Model.ANL”.
  • Use a macro-enabled Excel file with:

    • Sheet named “Column” with first row headers: Column No, Length, Breadth, Depth, Concrete Grade, Steel Grade, Reinforcement Area

      ColumnNoLengthBreadthDepthConcrete GradeSteel GradeReinforcement Area




    • Sheet named “Beam” with first row headers: Beam No, Length, Breadth, Depth, Concrete Grade, Steel Grade, T@0, T@0.25, T@0.5, T@0.75, T@1, B@0, B@0.25, B@0.5, B@0.75, B@1

      BeamNoLengthBreadthDepthConcrete GradeSteel GradeT@0T@0.25T@0.5T@0.75T@1B@0B@0.25B@0.5B@0.75B@1




    • Create a new module and add the ExtractData method:

      1
2
3

      Sub ExtractData()
'Add your code here
End Sub

I am using STAAD Connect Edition to generate my ANL file. If your ANL file structure is a bit different or you’re trying to extract different values, you will need to make some adjustments, specifically with line numbers.

Extract Data from ANL File

  • We can divide this task into multiple sub-tasks:
    • Reading data from the ANL file and storing it for further processing.
    • Finding the line number for a specific section as per our requirement.
    • Extracting data from lines that contain the required data.

Load Data from ANL file

  • The ANL file is just a text file with a custom file extension.
  • So we can read it like a text file using VBA.
  • Here we are storing data in a string collection, line by line, for easier access to each line.
  • For the file path, we are going to use ThisWorkbook.Path & "\Model.ANL".
1
2
3
4
5

Sub ExtractData()
    'Read ANL file into a collection
    Dim data As Collection
    Set data = ReadANL(ThisWorkbook.Path & "\Model.ANL")
End Sub

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

Function ReadANL(filePath As String) As Collection

    'Create new collection to store lines from the ANL file
    Dim data As Collection
    Set data = New Collection

    'Using File system utility to work with files and folders
    Dim fso As Object
    Set fso = CreateObject("Scripting.FileSystemObject")

    'Read ANL file line by line and load it to data collection
    Dim textStream As Object
    Dim line As String
    If fso.FileExists(filePath) Then
        Set textStream = fso.OpenTextFile(filePath, 1) ' ForReading = 1
        Do While Not textStream.AtEndOfStream
            line = textStream.ReadLine
            data.Add line
        Loop
        textStream.Close
    End If

    Set ReadANL = data
End Function

Find ANL file from Folder

  • This part is only required if you don’t use a fixed name for your STAAD model.
  • If you don’t know the ANL file name in advance, you have to write additional code to automatically find the ANL file from the folder.
1
2
3
4
5
6
7
8
9
10
11
12
13

Sub ExtractData()
    Dim filePath As String
    filePath = GetAnlFilePath()

    If filePath = "" Then
        MsgBox "No .ANL file found in the folder.", vbExclamation
        Exit Sub
    End If

    'Read ANL file into a collection
    Dim data As Collection
    Set data = ReadANL(filePath)
End Sub

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

Public Function GetAnlFilePath() As String

    'Using File system utility to work with files and folders
    Dim fso As Object
    Set fso = CreateObject("Scripting.FileSystemObject")

    'Get the folder containing the workbook
    Dim folder As Object
    Set folder = fso.GetFolder(ThisWorkbook.Path)

    'Loop through all files in folder and find .ANL file
    Dim file As Object
    For Each file In folder.Files
        If LCase(fso.GetExtensionName(file.Name)) = "anl" Then
            GetAnlFilePath = file.Path
            Exit Function
        End If
    Next

    GetAnlFilePath = ""
End Function

Find row with specific section

  • You have to adjust this part depending on which data you need to extract from the ANL file.
  • I’ve added sample code for extracting Column and Beam Design data.
  • Here we’re just looping through all lines and finding rows that match our criteria.
1
2
3
4
5
6
7
8
9
10
11

Sub ExtractData()
    'Read ANL file into a collection
    Dim data As Collection
    Set data = ReadANL(ThisWorkbook.Path & "\Model.ANL")

    'Extract Column data
    ExtractColumnData data

    'Extract Beam data
    ExtractBeamData data
End Sub

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

Private Sub ExtractColumnData(data As Collection)

    Dim ws As Worksheet
    Set ws = ThisWorkbook.Sheets("Column")

    'Loop through all lines and print lines containing C O L U M N   N O.
    Dim i As Long, rowId As Long, columnNo As Long
    rowId = 2

    For i = 1 To data.Count
        If InStr(1, data(i), "C O L U M N   N O.", vbTextCompare) > 0 Then
           columnNo = GetNumber(data(i), 1)
           If columnNo > 0 Then
            ws.Cells(rowId, 1).Value = columnNo
            rowId = rowId + 1
           End If
        End If
    Next i
End Sub

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18

Private Sub ExtractBeamData(data As Collection)
    Dim ws As Worksheet
    Set ws = ThisWorkbook.Sheets("Beam")

    'Loop through all lines and print lines containing B E A M  N O.
    Dim i As Long, rowId As Long, beamNo As Long
    rowId = 2

    For i = 1 To data.Count
        If InStr(1, data(i), "B E A M  N O.", vbTextCompare) > 0 Then
           beamNo = GetNumber(data(i), 1)
           If beamNo > 0 Then
            ws.Cells(rowId, 1).Value = beamNo
            rowId = rowId + 1
           End If
        End If
    Next i
End Sub

Extract Data from line

  • Once we find a line that contains the required results, we need code to extract specific results from that string.
  • For this, we have 3 common functions which will extract a number, decimal, or string from a given string.
  • Here, the numberIndex variable is used to specify which value to extract from the string:
    • numberIndex=1 means extract the first value from the string
    • numberIndex=2 means extract the second value from the string
    • numberIndex=3 means extract the third value from the string
  • We can use these functions in combination with our find matching row code.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

Private Sub ExtractColumnData(data As Collection)

    Dim ws As Worksheet
    Set ws = ThisWorkbook.Sheets("Column")

    'Loop through all lines and print lines containing C O L U M N   N O.
    Dim i As Long, rowId As Long, columnNo As Long
    rowId = 2

    For i = 1 To data.Count
        If InStr(1, data(i), "C O L U M N   N O.", vbTextCompare) > 0 Then
           columnNo = GetNumber(data(i), 1)
           If columnNo > 0 Then
            ws.Cells(rowId, 1).Value = columnNo 'Column No
            ws.Cells(rowId, 2).Value = GetDecimal(data(i + 4), 1) ' Length
            ws.Cells(rowId, 3).Value = GetDecimal(data(i + 4), 2) ' Breadth
            ws.Cells(rowId, 4).Value = GetDecimal(data(i + 4), 3) ' Depth
            ws.Cells(rowId, 5).Value = GetString(data(i + 2), 1) ' Concrete Grade
            ws.Cells(rowId, 6).Value = GetString(data(i + 2), 2) ' Steel Grade
            ws.Cells(rowId, 7).Value = GetDecimal(data(i + 9), 1) ' Reinforcement Area
            rowId = rowId + 1
           End If
        End If
    Next i
End Sub

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

Function GetNumber(line As String, numberIndex As Long) As Long
    Dim parts() As String
    parts = Split(line, " ")
    'Loop through all parts and return the first number
    Dim i As Long
    Dim matchCount As Integer
    For i = LBound(parts) To UBound(parts)
        If IsNumeric(parts(i)) Then
            matchCount = matchCount + 1
            If matchCount = numberIndex Then
                GetNumber = CLng(parts(i))
                Exit Function
            End If
        End If
    Next i
    GetNumber = 0
End Function

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

Function GetDecimal(line As String, numberIndex As Long) As Double
    Dim parts() As String
    parts = Split(line, " ")
    'Loop through all parts and return the first number
    Dim i As Long
    Dim matchCount As Integer
    For i = LBound(parts) To UBound(parts)
        If IsNumeric(parts(i)) Then
            matchCount = matchCount + 1
            If matchCount = numberIndex Then
                GetDecimal = CDbl(parts(i))
                Exit Function
            End If
        End If
    Next i
    GetDecimal = 0
End Function

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

Function GetString(line As String, numberIndex As Long) As String
    Dim parts() As String
    parts = Split(line, " ")
    'Loop through all parts and return the first string
    Dim i As Long
    Dim matchCount As Integer
    For i = LBound(parts) To UBound(parts)
        If Len(Trim(parts(i))) > 0 And Not IsNumeric(parts(i)) Then
            matchCount = matchCount + 1
            If matchCount = numberIndex Then
                GetString = CStr(parts(i))
                Exit Function
            End If
        End If
    Next i
    GetString = ""
End Function

Final Version

  • This is the final version of the code, combining all functions to extract column and beam design data.
  • Additionally, I’ve added the ClearExistingDataFromSheet method to clear existing data from the sheet before writing new data.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200

Sub ExtractData()
    Dim filePath As String
    filePath = GetAnlFilePath()

    If filePath = "" Then
        MsgBox "No .ANL file found in the folder.", vbExclamation
        Exit Sub
    End If

    'Clear existing data
    ClearExistingDataFromSheet "Column"
    ClearExistingDataFromSheet "Beam"

    'Read ANL file into a collection
    Dim data As Collection
    Set data = ReadANL(filePath)

    'Extract Column data
    ExtractColumnData data

    'Extract Beam data
    ExtractBeamData data
End Sub

Public Function GetAnlFilePath() As String

    'Using File system utility to work with files and folders
    Dim fso As Object
    Set fso = CreateObject("Scripting.FileSystemObject")

    'Get the folder containing the workbook
    Dim folder As Object
    Set folder = fso.GetFolder(ThisWorkbook.Path)

    'Loop through all files in folder and find .ANL file
    Dim file As Object
    For Each file In folder.Files
        If LCase(fso.GetExtensionName(file.Name)) = "anl" Then
            GetAnlFilePath = file.Path
            Exit Function
        End If
    Next

    GetAnlFilePath = ""
End Function

Function ReadANL(filePath As String) As Collection

    'Create new collection to store lines from the ANL file
    Dim data As Collection
    Set data = New Collection

    'Using File system utility to work with files and folders
    Dim fso As Object
    Set fso = CreateObject("Scripting.FileSystemObject")

    'Read ANL file line by line and load it to data collection
    Dim textStream As Object
    Dim line As String
    If fso.FileExists(filePath) Then
        Set textStream = fso.OpenTextFile(filePath, 1) ' ForReading = 1
        Do While Not textStream.AtEndOfStream
            line = textStream.ReadLine
            data.Add line
        Loop
        textStream.Close
    End If

    Set ReadANL = data
End Function

Private Sub ClearExistingDataFromSheet(sheetName As String)
    Dim ws As Worksheet
    Set ws = ThisWorkbook.Sheets(sheetName)
    With ws.Range("A1").CurrentRegion
        If .Rows.Count > 1 Then
            .Offset(1, 0).Resize(.Rows.Count - 1).EntireRow.Delete
        End If
    End With
End Sub

Private Sub ExtractColumnData(data As Collection)

    Dim ws As Worksheet
    Set ws = ThisWorkbook.Sheets("Column")

    'Loop through all lines and print lines containing C O L U M N   N O.
    Dim i As Long, rowId As Long, columnNo As Long
    rowId = 2

    For i = 1 To data.Count
        If InStr(1, data(i), "C O L U M N   N O.", vbTextCompare) > 0 Then
           columnNo = GetNumber(data(i), 1)
           If columnNo > 0 Then
            ws.Cells(rowId, 1).Value = columnNo 'Column No
            ws.Cells(rowId, 2).Value = GetDecimal(data(i + 4), 1) ' Length
            ws.Cells(rowId, 3).Value = GetDecimal(data(i + 4), 2) ' Breadth
            ws.Cells(rowId, 4).Value = GetDecimal(data(i + 4), 3) ' Depth
            ws.Cells(rowId, 5).Value = GetString(data(i + 2), 1) ' Concrete Grade
            ws.Cells(rowId, 6).Value = GetString(data(i + 2), 2) ' Steel Grade
            ws.Cells(rowId, 7).Value = GetDecimal(data(i + 9), 1) ' Reinforcement Area
            rowId = rowId + 1
           End If
        End If
    Next i
End Sub

Private Sub ExtractBeamData(data As Collection)

    Dim ws As Worksheet
    Set ws = ThisWorkbook.Sheets("Beam")

    'Loop through all lines and print lines containing B E A M  N O.
    Dim i As Long, rowId As Long, beamNo As Long
    rowId = 2

    For i = 1 To data.Count
        If InStr(1, data(i), "B E A M  N O.", vbTextCompare) > 0 Then
           beamNo = GetNumber(data(i), 1)
           If beamNo > 0 Then
            ws.Cells(rowId, 1).Value = beamNo ' Beam No
            ws.Cells(rowId, 2).Value = GetDecimal(data(i + 4), 1) ' Length
            ws.Cells(rowId, 3).Value = GetDecimal(data(i + 4), 2) ' Breadth
            ws.Cells(rowId, 4).Value = GetDecimal(data(i + 4), 3) ' Depth
            ws.Cells(rowId, 5).Value = GetString(data(i + 2), 1) ' Concrete Grade
            ws.Cells(rowId, 6).Value = GetString(data(i + 2), 2) ' Steel Grade

            'Top Reinforcement
            ws.Cells(rowId, 7).Value = GetDecimal(data(i + 11), 1) 'Top Reinforcement Area @ 0Length
            ws.Cells(rowId, 8).Value = GetDecimal(data(i + 11), 2) 'Top Reinforcement Area @ 0.25Length
            ws.Cells(rowId, 9).Value = GetDecimal(data(i + 11), 3) 'Top Reinforcement Area @ 0.5Length
            ws.Cells(rowId, 10).Value = GetDecimal(data(i + 11), 4) 'Top Reinforcement Area @ 0.75Length
            ws.Cells(rowId, 11).Value = GetDecimal(data(i + 11), 5) 'Top Reinforcement Area @ 1Length

            'Bottom Reinforcement
            ws.Cells(rowId, 12).Value = GetDecimal(data(i + 14), 1) 'Bottom Reinforcement Area @ 0Length
            ws.Cells(rowId, 13).Value = GetDecimal(data(i + 14), 2) 'Bottom Reinforcement Area @ 0.25Length
            ws.Cells(rowId, 14).Value = GetDecimal(data(i + 14), 3) 'Bottom Reinforcement Area @ 0.5Length
            ws.Cells(rowId, 15).Value = GetDecimal(data(i + 14), 4) 'Bottom Reinforcement Area @ 0.75Length
            ws.Cells(rowId, 16).Value = GetDecimal(data(i + 14), 5) 'Bottom Reinforcement Area @ 1Length

            rowId = rowId + 1
           End If
        End If
    Next i
End Sub

Function GetNumber(line As String, numberIndex As Long) As Long
    Dim parts() As String
    parts = Split(line, " ")
    'Loop through all parts and return the first number
    Dim i As Long
    Dim matchCount As Integer
    For i = LBound(parts) To UBound(parts)
        If IsNumeric(parts(i)) Then
            matchCount = matchCount + 1
            If matchCount = numberIndex Then
                GetNumber = CLng(parts(i))
                Exit Function
            End If
        End If
    Next i
    GetNumber = 0
End Function

Function GetDecimal(line As String, numberIndex As Long) As Double
    Dim parts() As String
    parts = Split(line, " ")
    'Loop through all parts and return the first number
    Dim i As Long
    Dim matchCount As Integer
    For i = LBound(parts) To UBound(parts)
        If IsNumeric(parts(i)) Then
            matchCount = matchCount + 1
            If matchCount = numberIndex Then
                GetDecimal = CDbl(parts(i))
                Exit Function
            End If
        End If
    Next i
    GetDecimal = 0
End Function

Function GetString(line As String, numberIndex As Long) As String
    Dim parts() As String
    parts = Split(line, " ")
    'Loop through all parts and return the first string
    Dim i As Long
    Dim matchCount As Integer
    For i = LBound(parts) To UBound(parts)
        If Len(Trim(parts(i))) > 0 And Not IsNumeric(parts(i)) Then
            matchCount = matchCount + 1
            If matchCount = numberIndex Then
                GetString = CStr(parts(i))
                Exit Function
            End If
        End If
    Next i
    GetString = ""
End Function

Conclusion

  • I’ve written this code so users can easily modify it as per their specific requirements.
  • The current version of the code is written to be beginner-friendly and is not optimized for large models.
  • You might need to do some optimization if you want to reduce execution time for large models.
VBA, VBA-STAAD
excel staad vba openstaad how to
This post is licensed under CC BY-NC-ND 4.0 by the author.
