How to Extract Results from STAAD to Excel Using VBA

Use OpenSTAAD API to extract results from a STAAD model

Posted
Preview Image
By Vivek Patel
7 min read
How to Extract Results from STAAD to Excel Using VBA

Overview

  • In this tutorial, I’ll show you how to extract results from the active STAAD model to your Excel file.
  • Why automate this process?
    • You can extract multiple results from different sections.
    • You can perform post-processing on original results to convert them into your desired format.
    • Integrate results extraction code with your design sheet for a simpler workflow.
  • I am assuming that:
    • You have a basic knowledge of VBA and know how to add modules and create new subs.
    • You’re familiar with STAAD and know how to check results manually to compare them with the code output.
  • OpenSTAAD Reference
  • If you’re using STAAD CONNECT Edition, you can open File > Help > OpenSTAAD Help. These docs are better than the online version.

Setup

  • We are going to use two files:
  • STAAD Model
    • For this tutorial, we’re just going to use a single-span fixed beam. Just copy this STAAD Model.
    • You’re free to use any model you like but make sure that you can verify output results to simplify your testing.
  • Excel
    • Create a macro-enabled Excel file.
    • We are going to print all results in the active sheet, column A.
    • Use the sample code below to print your output.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

Sub GetResults()
    'Clear All Previous Results
    ActiveSheet.Range("A1").CurrentRegion.ClearContents

    'You can print your output using GetNextCell() Function
    GetNextCell().Value = "Hello, My Name is Vivek"
    GetNextCell().Value = "This is a demo for STAAD OpenSTAAD API using Excel VBA"
End Sub

' Function to get the next empty cell in column A
Private Function GetNextCell() As Range
    If ActiveSheet.Range("A1").CurrentRegion.Rows.Count = 1 And IsEmpty(ActiveSheet.Range("A1")) Then
        Set GetNextCell = ActiveSheet.Range("A1")
    Else
        Set GetNextCell = ActiveSheet.Cells(ActiveSheet.Range("A1").CurrentRegion.Rows.Count + 1, 1)
    End If
End Function

Extract Results

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

Sub GetResults()
    'Clear All Previous Results
    ActiveSheet.Range("A1").CurrentRegion.ClearContents

    'Create OpenSTAAD Object
    Dim objOpenSTAAD As Object
    Set objOpenSTAAD = GetObject(, "StaadPro.OpenSTAAD")

    'Commonly Used Variables
    'Using Long types instead of Integer to use this with OpenSTAAD
    Dim i As Long, j As Long
    Dim nodeId As Long, beamId As Long, loadCaseId As Long

    '<<< Add Remaining Code Here >>>
End Sub

Support Reactions

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

'Populate Support Reaction Array for Node 1 in Load Case 1
nodeId = 1
loadCaseId = 1
Dim supportReactions(6) As Double
objOpenSTAAD.Output.GetSupportReactions nodeId, loadCaseId, supportReactions

'Print Support Reactions in sequence of Fx, Fy, Fz, Mx, My, Mz
GetNextCell().Value = "Support Reactions for Node: " & nodeId & ", Load Case: " & loadCaseId
'Divide by 9.80665 to convert kN to MTon
GetNextCell().Value = supportReactions(0) / 9.80665 'Fx
GetNextCell().Value = supportReactions(1) / 9.80665 'Fy
GetNextCell().Value = supportReactions(2) / 9.80665 'Fz
GetNextCell().Value = supportReactions(3) / 9.80665 'Mx
GetNextCell().Value = supportReactions(4) / 9.80665 'My
GetNextCell().Value = supportReactions(5) / 9.80665 'Mz

Section Forces (Axial Force, Shear Force, Bending Moments)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

'Print Beam Length
Dim beamLength As Double
beamId = 1
beamLength = objOpenSTAAD.Geometry.GetBeamLength(beamId)
GetNextCell().Value = "Beam Length: " & beamLength

'Calculate distance from Start of Beam
Dim distance As Double
distance = 0.5 * beamLength 'Mid-Span

'Print Beam Section Forces at Mid-Span
beamId = 1
loadCaseId = 1
Dim sectionForces(6) As Double
objOpenSTAAD.Output.GetIntermediateMemberForcesAtDistance beamId, distance, loadCaseId, sectionForces

'Print Section Forces in sequence of Axial, Shear Y, Shear Z, Moment X, Moment Y, Moment Z
GetNextCell().Value = "Beam Section Forces at Mid-Span for Beam: " & beamId & ", Load Case: " & loadCaseId
'Divide by 9.80665 to convert kN to MTon
GetNextCell().Value = sectionForces(0) / 9.80665 'Axial
GetNextCell().Value = sectionForces(1) / 9.80665 'Shear Y
GetNextCell().Value = sectionForces(2) / 9.80665 'Shear Z
GetNextCell().Value = sectionForces(3) / 9.80665 'Moment X
GetNextCell().Value = sectionForces(4) / 9.80665 'Moment Y
GetNextCell().Value = sectionForces(5) / 9.80665 'Moment Z
  • By default, STAAD divides each section into 12 parts, so it will show you section forces at 13 points for each load.
  • If you need results in this format, use the sample code below.
1
2
3
4
5
6
7

'Print Section Forces at 12 equally spaced points along the beam
GetNextCell().Value = "Beam Section Forces at 12 equally spaced points along the beam for Beam: " & beamId & ", Load Case: " & loadCaseId
For i = 0 To 12
    distance = i * beamLength / 12
    objOpenSTAAD.Output.GetIntermediateMemberForcesAtDistance beamId, distance, loadCaseId, sectionForces
    GetNextCell().Value = sectionForces(0) & "," & sectionForces(1) & "," & sectionForces(2) & "," & sectionForces(3) & "," & sectionForces(4) & "," & sectionForces(5)
Next

Plate Stresses and Moments

  • Not relevant to this beam model, but here is sample code to extract plate stresses and moments.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

'Populate Plate Center Stresses and Moments for Plate 1 in Load Case 1
Dim plateId As Long
plateId = 1
loadCaseId = 1

Dim plateStresses(8) As Double
objOpenSTAAD.Output.GetAllPlateCenterStressesAndMoments plateId, loadCaseId, plateStresses
GetNextCell().Value = plateStresses(0) / 9.80665 'SQx
GetNextCell().Value = plateStresses(1) / 9.80665 'SQy
GetNextCell().Value = plateStresses(2) / 9.80665 'Mx
GetNextCell().Value = plateStresses(3) / 9.80665 'My
GetNextCell().Value = plateStresses(4) / 9.80665 'Mxy
GetNextCell().Value = plateStresses(5) / 9.80665 'Sx
GetNextCell().Value = plateStresses(6) / 9.80665 'Sy
GetNextCell().Value = plateStresses(7) / 9.80665 'Sz

Node Displacement

  • Not relevant to this model, but deflection check is a common design requirement.
1
2
3
4
5
6
7
8
9
10
11
12

'Populate Displacement Array for Node 1 in Load Case 1
nodeId = 1
loadCaseId = 1
Dim displacements(6) As Double
objOpenSTAAD.Output.GetNodeDisplacements nodeId, loadCaseId, displacements
GetNextCell().Value = "Node " & nodeId & " Displacements in Load Case " & loadCaseId
GetNextCell().Value = "Dx: " & displacements(0)
GetNextCell().Value = "Dy: " & displacements(1)
GetNextCell().Value = "Dz: " & displacements(2)
GetNextCell().Value = "Rx: " & displacements(3)
GetNextCell().Value = "Ry: " & displacements(4)
GetNextCell().Value = "Rz: " & displacements(5)

Get Model Unit

  • Checking the model unit is not required in most cases since the user will already know the units of their model.
  • Knowing model units may come in handy when you’re working with a model from an external source or making a generalized tool.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

'Print Model Unit
'Return value (1 for English system, 2 for Metric system)
Dim baseUnit As String
baseUnit = objOpenSTAAD.GetBaseUnit
GetNextCell().Value = "Base Unit: " & baseUnit

'Print Length Unit for Length
'Return value  (0- Inch, 1- Feet, 2- Feet, 3- Centimeter, 4- Meter, 5- Millimeter, 6- Decimeter, 7 – Kilometer)
Dim lengthUnit As String
lengthUnit = objOpenSTAAD.GetInputUnitForLength
GetNextCell().Value = "Model Unit: " & lengthUnit

'Print Force Unit for Force
'Return value (0- Kilopound, 1- Pound, 2- Kilogram, 3- Metric Ton, 4- Newton, 5- Kilonewton, 6- Meganewton, 7- Decanewton)
Dim forceUnit As String
forceUnit = objOpenSTAAD.GetInputUnitForForce
GetNextCell().Value = "Force Unit: " & forceUnit

Fixed Beam STAAD Model

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37

STAAD SPACE
START JOB INFORMATION
ENGINEER DATE 15-May-25
END JOB INFORMATION
INPUT WIDTH 79
UNIT METER MTON
JOINT COORDINATES
1 0 0 0; 2 3 0 0;
MEMBER INCIDENCES
1 1 2;
DEFINE MATERIAL START
ISOTROPIC CONCRETE
E 2.21467e+006
POISSON 0.17
DENSITY 2.40262
ALPHA 1e-005
DAMP 0.05
TYPE CONCRETE
STRENGTH FCU 2812.28
END DEFINE MATERIAL
MEMBER PROPERTY AMERICAN
1 PRIS YD 0.3 ZD 0.3
CONSTANTS
MATERIAL CONCRETE ALL
SUPPORTS
1 2 FIXED
LOAD 1 LOADTYPE None  TITLE DEAD LOAD
MEMBER LOAD
1 UNI GY -10
LOAD 2 LOADTYPE None  TITLE LIVE LOAD
MEMBER LOAD
1 CON GY -50 1.5 0
LOAD COMB 101 ULTIMATE LOAD
1 1.5 2 1.3
PERFORM ANALYSIS
PERFORM ANALYSIS
FINISH

Conclusion

  • Using a VBA macro to extract results is one of the most popular use cases.
  • There is no major downside to this automation.
  • The only downside I can think of is that you’ll need a good system to identify each element and loads.
